Streamlight ProTac Rail Mount HL-X


In Stock

Video | What’s Included | Specs | Pictures | FAQ | Restrictions | Related Info

The Streamlight ProTac Rail Mount HL-X is one of the best out of the box rifle lights that you can get if you are on a budget. This light has an excellent output of 1,000 Lumens and 27,600 Candela, which will give you the capability to illuminate up close and at intermediate distances. This Rail Mount HL-X includes everything you need to mount it on a rifle, including a pressure pad. So, if you are looking for a budget rifle light that comes with everything you need, the Streamlight ProTac Rail Mount HL-X might be one to consider.

And if you’re looking for a pressure pad mounting solution that is neither zip ties nor adhesive tape, check out the Cloud Defensive Light Control System.


Back to top ↑


One Streamlight ProTac Rail Mount HL-X light; Two CR123A lithium batteries; Remote pressure switch: Push-button tail switch; Remote retaining clips; Two screws; Double-sided tape; Two 11″ zip ties; Two 3.5″ zip ties; Operating instruction manual; One Streamlight sticker.

Back to top ↑



  • Integrated rail clamp attaches to MIL-STD-1913 rails (Picatinny).
  • TEN-TAP Programming allows selection of three different operating programs: 1) high/strobe; 2) high only; 3) low/high.
  • Easy to use pressure switch comes with a button for on/off and a pressure switch for momentary activation.
  • Durable, anodized aluminum construction with impact-resistant tempered glass lens.
  • Dual fuel – uses two CR123A lithium batteries (included); also accepts one Streamlight SL-B26 protected Li-Ion USB rechargeable battery pack (RoHS compliant).
  • Solid State power regulation provides maximum light output throughout battery life.
  • IPX7 rated with the Standard button switch installed; Waterproof to 1 meter for 30 minutes. IPX4 rated with the Remote Pressure Switch installed.
  • Operating temperature: -40°F to +120°F

Limited lifetime warranty.
Made in China.

View the Fact Sheet HERE, Operating Instructions HERE, Data Sheet HERE, and Parts Sheet HERE.


High Lumens1,000
Run Time on High1.25 hours
Run Time on Low20.00 hours
Beam Distance332 meters
Max Candela27,600
Battery TypeStreamlight SL-B26 Protected Li-Ion USB Rechargeable Battery Pack, CR123A Lithium
Battery Quantity2
Length5.43 in. (13.79 cm)
Weight6.40 oz. (181.44 g) – 6.90 oz. (195.61 g)

Back to top ↑


Back to top ↑


Does this work with mounts that use a SureFire Scout Mount Footprint?
Affirmative. The Streamlight HL-X body mounts using the same scout-style footprint.
Can I use a SureFire pressure pad with this?
Not without an adapter. Arisaka makes one that we like.
What kind of batteries does this take?
The HL-X is technically a dual fuel light— it can run off of two CR123s or one 18650.

Back to top ↑


This product contains lithium and cannot be shipped outside of the contiguous 48 United States.
